Fairchild
M20BP
FAIRCHILD - Volume Boosters
The Model 20BP is a smaller Back Pressure Pneumatic Booster designed for automated or remote controlling of the back pressure or relief operation typically found in tank systems and other pressurized systems.
Features
• Signal pressure of up to 150 psig [10.0 BAR] (1000kPa) and handles up 250 psig, [17.0 BAR], (1700 kPa) system pressure
• Flow capacity of 45 SCFM (76.5 m3/HR), which equates to a Cv factor of approximately 1.0 - fast responsive operation
• Aspirator tube design compensates downstream pressure droop under flow conditions
• A separate control chamber isolates the diaphragm from the main flow and eliminates hunting and buzzing
• Unit construction allows servicing without removal
• Mounting bracket available - easy installation in the field
