SPI Smart Position Indicator
SPI
The Smart Position Indicator (SPI) features limit switches enclosed in a IECEx / ATEX certified protective enclosure providing an accurate and reliable Open / Close signal to the control room for multi-turn manual valves. Using 30+ years of proven technology, the new SPI mechanically displays the position of the valve for in-field notification and digitally signals its open / closed position.
Features
• Multi-turn manual duty
• ISO5210 F10 output
• Anodised aluminium housing
• Stainless steel fasteners
• Protected shafts
• Adjustable open / shut plates & contacts
• Maintenance free
• Switches and terminals housed inside a protective enclosure
• Switches used: Bartec 07-1501-6, Pepperl+Fuchs NCB2-V3-N0, Crouzet 831391, Omron DV3-161, or equivalent (non-hazardous variants)
• Mount to existing F10 input flange (stem acceptance Ø20 x 60 mm)
• Direct mount to non-thrust taking, rising stem valve (max stem acceptance Ø20 x 100 mm from mounting face)
• ISO5210 F10 output
• Anodised aluminium housing
• Stainless steel fasteners
• Protected shafts
• Adjustable open / shut plates & contacts
• Maintenance free
• Switches and terminals housed inside a protective enclosure
• Switches used: Bartec 07-1501-6, Pepperl+Fuchs NCB2-V3-N0, Crouzet 831391, Omron DV3-161, or equivalent (non-hazardous variants)
• Mount to existing F10 input flange (stem acceptance Ø20 x 60 mm)
• Direct mount to non-thrust taking, rising stem valve (max stem acceptance Ø20 x 100 mm from mounting face)
Features
Features
• Multi-turn manual duty
• ISO5210 F10 output
• Anodised aluminium housing
• Stainless steel fasteners
• Protected shafts
• Adjustable open / shut plates & contacts
• Maintenance free
• Switches and terminals housed inside a protective enclosure
• Switches used: Bartec 07-1501-6, Pepperl+Fuchs NCB2-V3-N0, Crouzet 831391, Omron DV3-161, or equivalent (non-hazardous variants)
• Mount to existing F10 input flange (stem acceptance Ø20 x 60 mm)
• Direct mount to non-thrust taking, rising stem valve (max stem acceptance Ø20 x 100 mm from mounting face)
• ISO5210 F10 output
• Anodised aluminium housing
• Stainless steel fasteners
• Protected shafts
• Adjustable open / shut plates & contacts
• Maintenance free
• Switches and terminals housed inside a protective enclosure
• Switches used: Bartec 07-1501-6, Pepperl+Fuchs NCB2-V3-N0, Crouzet 831391, Omron DV3-161, or equivalent (non-hazardous variants)
• Mount to existing F10 input flange (stem acceptance Ø20 x 60 mm)
• Direct mount to non-thrust taking, rising stem valve (max stem acceptance Ø20 x 100 mm from mounting face)
Downloads
Product Brochures
PUB132-001 - Smart Position Indicator SPI datasheet - English (pdf)
Manuals
PUB132-002 - Smart Position Indicator SPI Instruction Manual - English (pdf)
Certificates
PUB132-005 - SPI Smart Position Indicator UKEx Certificate of Conformity - English (pdf)
PUB132-003 - SPI Smart Position Indicator ATEX 2014/34/EU Certificate of Conformity - English (pdf)
PUB132-004 - SPI Smart Position Indicator IECEx Certificate of Conformity - English (pdf)
