Insight 2
Insight 2 PC software is a graphical user interface (GUI) allowing all IQ3, CK, CVA and SI Pro set-up, configuration and data logger information to be reviewed, analysed and reconfigured.
The visually interactive standalone application makes analysing the data from Rotork Bluetooth® enabled actuators simple and fast. Laptops with compatible built-in Bluetooth® wireless technology or alternatively a USB Bluetooth® Dongle, running Insight 2 can be directly connected to an actuator located in the field to allow set up, adjustment and analysis.
Insight 2 Software for PC - Version 5.0.21 is fully compatible with Windows 10, 8, 7, Vista and XP (including touch screens) and supports USB-Bluetooth® adapter technology. Click here for a list of tested adapters.
Insight 2 is not compatible with the older IQmk2 - IQ Insight must be used instead.
Information on actuator specification, set up and operation can be shared between colleagues and sites and when required with Rotork representatives.
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc.
Minimum PC Operating Requirements
- Pentium class or equivalent processor
- 1GB RAM
- Minimum 800 x 600 monitor resolution
- Microsoft Windows XP, Vista, 7 and 8
- USB 1or 2 port
*While every effort has been made to ensure that Insight 2 works with these systems, individual operating system/PC set-up may affect operation. Insight 2 operation cannot be guaranteed with other operating systems. Rotork cannot be held responsible if Insight 2 or any of its parts does not work on any specific PC.
When prompted, save to a folder on your PC hard disk. On completion of download, browse to the folder selected for the download. Select setup.exe and open. Follow the onscreen instructions to install the program.Access Level - Viewer
Password: ROTORK
Access Level - User
Password: ROTACT
Please refer to GNU General Public License (GPL) for information on license agreement.
Software has been tested with insight on various operating platforms, however, Rotork accept no liability for errors caused by installing third party software.
ADF (Actuator Description File) update
ADF files are used to allow Insight 2 to display the correct parameters for each type of actuator. Each actuator type has its own ADF file and from time to time will be updated to include new parameters or new actuator ranges.
The ADF file update below update all of the ADF files in one go, making it easier for the user. Follow the link below for full instructions when updating the ADF files:
Instructions for updating Insight 2 ADF files
The ADF file updates are formatted in a .zip file. Once downloaded, do not extract the zip file as Insight 2 will automatically load it in the zipped format.
