IQ Pocket Insight
Pocket IQ® Insight software allows users to communicate with the IQ® actuator range using a hand-held Personal Digital Assistant (PDA). The software allows all IQ® set-up and configuration information to be reviewed, reconfigured and saved. Additionally, data logger information can also be retrieved and saved for later analysis using Rotork's PC IQ® Insight software.
Specifically designed for use with Pocket PC or Windows Mobile operating systems, Pocket IQ Insight will allow the user to gather actuator data and check or update configuration conveniently in the field.
Pocket IQ insight - PDA system requirements
- Connectivity: Infra-Red Port (IrDA)
- Operating System: Microsoft Pocket PC or Windows Mobile
- Free Memory: 500kB
While every effort has been made to ensure that Pocket IQ Insight works with these systems, individual operating system/PDA set-up may affect operation. Pocket IQ Insight operation cannot be guaranteed with all PDAs or other operating systems. Rotork cannot be held responsible if Pocket IQ Insight or any of its parts does not work on any specific PDA.
Instructions for download:
Select the program below, suitable for your PDA operating system. If you have a Microsoft Windows Mobile 5 or 6 device with an IrDA port built into the device, select the built-in IrDA port version. If you have a Microsoft Windows Mobile 5 or 6 device that uses an external IrDA dongle such as the iPAQ 214 and ActiSys ACT-IR120UD combination, then select the external IrDA dongle version. (Devices with Microsoft Pocket PC only had internal IrDA ports.)
- When prompted, save to a folder on your PC's hard disk, for example the Desktop. On completion of download, browse to the folder containing the saved zip archive and open it. Select Pocket IQ-Insight.exe and extract it to a folder of your choice on your PC.
- Transfer the Pocket Insight.exe file to your PDA via Synchronisation / share software such as Microsoft's Active Sync or Windows Mobile Device Center. Often, once connected to your PC, the PDA's file system can be opened in My Computer as an external drive. Make a note of which folder on your PDA you copy the Pocket Insight.exe file.
- Disconnect your PDA from the PC and using File Explorer or similar on the PDA, navigate to the location of Pocket Insight.exe and open it to run the program. There is no need to perform an installation, the program runs directly from the copied file.
Download Pocket IQ-Insight for Microsoft Pocket PC:
v2.5 - Pocket PC 2002/3
Pocket IQ-Insight log in:
Pocket-Insight username =user
Pocket-Insight password =user
Download Pocket IQ-Insight for Microsoft Windows Mobile 5 & 6: v2.5 - Devices with built-in IrDA port
Download Pocket IQ-Insight for Microsoft Windows Mobile 5 & 6:
v2.5 - Devices using external IrDA dongle
Download Application Notes:
Using Pocket InSight with the i.roc PDA and iPAQ with Actisys USB Dongle
